Specifications
|
|
|
Engine |
125cc / 150cc |
| Bore x Stroke | 54mm x 54mm / 58.5mm x 54mm |
| Compression Ratio | 9.0:1 / 10.0:1 |
| Max Power | 7.1kw (@8000rpm) / 8.1kw/(7700r/min) |
| Max Torque | 9.5N.m (@6500rpm) / 11.2N/m(5700r/min) |
| Ignition | CDI |
| Starter | Kick |
| Gearshift Pattern | 1-N-2-3-4-5 (1 up, 4 down) |
| Transmission | Front Sprocket 14T |
| Rear Sprocket 41T | |
| Chain KMC 428 | |
| Wheelbase | 1074mm |
| Seat Height | 668mm |
| Ground Clearance | 123mm |
| Dry Weight | 85kg |
| Length x Width x Height | 1556mm x 595mm x 911mm |
| Frame | Steel |
| Handle Bars | Steel with Alloy Clip On Clamps |
| Wheels | Alloy Front 3.00-12, Alloy Rear 3.50-12 |
| Tires | Front 100/80-12, Rear 120/80-12 |
| Front Forks | USD Fork Travel 100mm |
| Rear Shock | Common Travel 35mm |
| Swingarm | Steel Length=410mm |
| Brakes | Front Brake Disc |
| Rear Brake Disc | |
| Fork Angle | 23degrees36' |
| Fuel Capacity | 10 Liters |
|
|
